Tantalum Ntawv Nyiaj
Yam khoom: Tantalum Tungsten Disc, Ta Sheet / Ta Phaj, Ta Tube / Ta Pipe, Ta Capillary, Ta Wire, thiab Ta Bar / Ta Rod.
Hauj lwm lawm
ZhenAn Tantalum Sawb thiab Ntawv Nyiaj
Unalloyed tantalum ua tau raws li cov kev txwv ntawm ASTM F560 - R05200. Tantalum yog xaiv rau nws cov corrosion kuj, thermal conductivity, siab melting point, thiab muaj peev xwm tsim dielectric oxide films.
Tantalum yog qhov tsis tshua muaj ductile thiab tuaj yeem ua tau yooj yim txias vim nws qhov ua haujlwm qis qis. Vuam tuaj yeem ua tiav los ntawm kev tiv thaiv, TIG, lossis electron beam txoj kev, nrog kev saib xyuas los tiv thaiv qhov vuam thiab tshav kub cuam tshuam los ntawm cov huab cua thaum lub sij hawm vuam. Tantalum yuav tsum tsis txhob siv rau lub sijhawm ntev tshaj 260 degree hauv huab cua lossis lwm qhov chaw oxidizing tshwj tsis yog tias muaj kev tiv thaiv roj lossis lub tshuab nqus tsev, vim muaj peev xwm rau hydrogen embrittlement.
Ntshiab Tantalum Ntawv Nyiaj Muaj Qhov Loj
Tantalum yog muaj los ntawm ZhenAn raws li cov khoom siv strip los ntawm {{0}} 0005" mus rau 0.035" (0.0127 mm txog 0.889 mm) dav txog li. 12.0 "(304.8 mm) Cov khoom ua tau raws li UNS R05200 thiab ua tau raws li cov cai ntawm ASTM F560 thiab ASTM B708.
ZhenAn Tantalum Pieces Ntim
Pebtantalum nplooj ntawvyuav tau ntim rau hauv cov thawv ntoo thiab txhawb nqa nrog cov ntaub ntawv mos kom ntseeg tau tias cov khoom ntim yuav tsis txav mus rau hauv lub thawv ntoo.
Tantalum hlau Nominal Composition
| TANTALUM NOMINAL COMPOSITION | |
|---|---|
| Cov pa roj carbon | 0.010% |
| Oxygen | 0.0150% |
| Nitrogen | 0.010% |
| Hydrogen | 0.0015% |
| Niobium | 0.100% |
| Hlau | 0.010% |
| Titanium | 0.010% |
| Tungsten | 0.05% |
| Molybdenum | 0.020% |
| Silicon | 0.0050% |
| Nickel | 0.010% |
| Tantalum | Tshuav |
ZhenAn Mechanical Properties
| TANTALUM MECHANICAL PROPERTIES | ||
|---|---|---|
| TSEEM CEEB | ROLLED (90%) | |
| Qhov kawg Tensile Strength | 40, 000 PSI | 125, 000 PSI |
| Yield zog (0.2% Offset) | 26, 000 PSI | 118, 000 PSI |
| Elongation hauv 2 "* | 50% | 2% |
| Modulus ntawm Elasticity (Tension) | 26 X 106PSI | - |
| Hardness | 35 HR ib | 20 HRC |
Tantalum tseem tuaj yeem muab rau hauv qhov txias txias thiab txo qhov kev ntxhov siab rau ASTM F560 txwv.
* Qhov ntsuas elongation yuav tsawg dua li thickness txo rau 0.002" thiab tsawg dua.
Cov txiaj ntsig no tuaj yeem hloov kho los ntawm kev tswj cov txheej txheem hloov pauv.
ZhenAn Lub Cev Khoom
| TANTALUM PHYSICAL PROPERTIES | |
|---|---|
| Qhov ntom | 0.602 lb/in3 |
| Melting Point | 2996 degree |
| Hluav taws xob tiv thaiv @ RT | 12.5 hli |
| Thermal conductivity @ RT | 54.4 W/m·K |
| Thermal Expansion Coefficient (20 rau 500 degree) (20 rau 1000 degree) |
6.7 X 10-6 6.96 X 10-6/ degree |
| Kub Coefficient ntawm Resistivity | 3820 ppm / degree |
Cov txiaj ntsig zoo los qhia kev xaiv alloy tab sis tsis yog qhov lav ntawm qhov tsawg kawg nkaus lossis siab kawg.
Vim li cas thiaj xaiv peb?
1. Muaj peev xwm R & D muaj zog
2. Ntau tshaj 30 xyoo ntawm kev paub hauv R & D thiab tsim cov khoom siv hlau
3. Kev lag luam hauv xeev, credit zoo, muaj zog nyiaj txiag
4. Kev pabcuam ib leeg rau txhua yam ntawm cov hlau refractory thiab cov hlau tsis tshua muaj
5. Pab neeg muag khoom, kev pabcuam tag nrho.
Cim npe nrov: tantalum ntawv ci
